Module handling the time memory of the resonance condition along the orbit, which allows time derivatives to be evaluated. More...
Collaboration diagram for RFOF_resonance_memory:Data Types | |
| type | resonance_memory |
| Storage structure for for the memory of the resonance function. It has two purposes within RFOF: More... | |
Public Member Functions | |
| subroutine | constructor_rf_resonance_memory (mem, nStoreTimes) |
| Constructor for the type resonance_memory. Allocates memory and initialises counters and state variables. | |
| subroutine | destructor_rf_resonance_memory (mem) |
| Destructor for the type resonance_memory. Deallocates memory. | |
| subroutine | reset_rf_resonance_memory (mem) |
| Reset the resonance memory. | |
| subroutine | reset_rf_resonance_memory_matrix (mem) |
| Reset a matrix of resonance memories. | |
| subroutine | constructor_rf_resonance_memory_matrix (mem, nWaves1, nWaves2) |
| Constructor of a matrix of the type resonance_memory. Allocates memory and initialises counters and state variables. | |
| subroutine | destructor_rf_resonance_memory_matrix (mem) |
| Destructor for a matrix of the type resonance_memory. Deallocates memory. | |
| subroutine | storeNewPointResonanceMemorySort (mem, time_at_resonance, time, nharm, NACC, R, phi, z, omega_res, omega_c, was_stored) |
| Stores a new point in the memory. The memory is kept sorted in time, always keeping the latest times first. In case the the new point is earlier in time than all points already in the memory, then the point is not stored and the output was_stored=.FALSE. | |
| subroutine | storeNewPointResonanceMemory (mem, time_at_resonance, time, nharm, NACC, R, phi, z, omega_res, omega_c, was_stored) |
| Stores a new point in the memory mem. The new point is stored in the first element. All other points are moved one place in the memory list, except the last point which is removed from the list. | |
| subroutine | storeNewPointResonanceMemoryLocationJ (mem, j, time, R, phi, z, omega_res, omega_c, nharm, NACC) |
| subroutine storeNewPointResonanceMemory | |
| subroutine | estimate_resonance_location (mem, time, R, phi, z, omega_res, nharm, NACC, time_previous_step, time_at_resonance, R_at_resonance, phi_at_resonance, z_at_resonance, Dot_omega_res, DotDot_omega_res, MPI_node_Id, errorFlag) |
| Estimate the time and position of the nearby wave-particle resonances. Using the time history of the resonance function a quadratic extrapolation of the future position is performed. | |
| subroutine | calc_non_accelerated_orbit_time_vec (timeACC, NACC, timeORBIT) |
| Estimate the time and position of the nearby wave-particle resonances. Using the time history of the resonance function a quadratic extrapolation of the future position is performed. | |
Public Attributes | |
| type(resonance_memory), dimension(:,:), allocatable, save | resonanceMemoryAllWaves |
Module handling the time memory of the resonance condition along the orbit, which allows time derivatives to be evaluated.
Definition at line 10 of file RFOF_resonance_memory.F90.
| subroutine RFOF_resonance_memory::constructor_rf_resonance_memory | ( | type(resonance_memory), intent(inout) | mem, |
| integer, intent(inout) | nStoreTimes | ||
| ) |
Constructor for the type resonance_memory. Allocates memory and initialises counters and state variables.
| mem | Resonance memory information to be initialised |
| nStoreTimes | Number of time points to be stored in the resonance memory |
Definition at line 58 of file RFOF_resonance_memory.F90.
| subroutine RFOF_resonance_memory::destructor_rf_resonance_memory | ( | type(resonance_memory), intent(inout) | mem | ) |
Destructor for the type resonance_memory. Deallocates memory.
| mem | Resonance memory information to be deallocated |
Definition at line 89 of file RFOF_resonance_memory.F90.
| subroutine RFOF_resonance_memory::reset_rf_resonance_memory | ( | type(resonance_memory), intent(inout) | mem | ) |
Reset the resonance memory.
| mem | Resonance memory to be reset |
Definition at line 140 of file RFOF_resonance_memory.F90.
| subroutine RFOF_resonance_memory::reset_rf_resonance_memory_matrix | ( | type(resonance_memory), dimension(:,:), intent(inout), pointer | mem | ) |
Reset a matrix of resonance memories.
| mem | Resonance memory matrix to be reset |
Definition at line 156 of file RFOF_resonance_memory.F90.
| subroutine RFOF_resonance_memory::constructor_rf_resonance_memory_matrix | ( | type(resonance_memory), dimension(:,:), intent(out), pointer | mem, |
| integer, intent(in) | nWaves1, | ||
| integer, intent(in) | nWaves2 | ||
| ) |
Constructor of a matrix of the type resonance_memory. Allocates memory and initialises counters and state variables.
| mem | Resonance memory information to be initialised |
| nWaves1 | Size of matrix in first dimension |
| nWaves2 | Size of matrix in second dimension |
Definition at line 183 of file RFOF_resonance_memory.F90.
| subroutine RFOF_resonance_memory::destructor_rf_resonance_memory_matrix | ( | type(resonance_memory), dimension(:,:), intent(inout), pointer | mem | ) |
Destructor for a matrix of the type resonance_memory. Deallocates memory.
| mem | Resonance memory information to be deallocated |
Definition at line 220 of file RFOF_resonance_memory.F90.
| subroutine RFOF_resonance_memory::storeNewPointResonanceMemorySort | ( | type(resonance_memory), intent(inout) | mem, |
| real(8), intent(in) | time_at_resonance, | ||
| real(8), intent(in) | time, | ||
| integer, intent(in) | nharm, | ||
| real(8), intent(in) | NACC, | ||
| real(8), intent(in) | R, | ||
| real(8), intent(in) | phi, | ||
| real(8), intent(in) | z, | ||
| real(8), intent(in) | omega_res, | ||
| real(8), intent(in) | omega_c, | ||
| logical, intent(out) | was_stored | ||
| ) |
Stores a new point in the memory. The memory is kept sorted in time, always keeping the latest times first. In case the the new point is earlier in time than all points already in the memory, then the point is not stored and the output was_stored=.FALSE.
INPUT
| time_at_resonance | Estimated time of the resonance [s] |
| time | Present time [s] |
| nharm | Harmonic number of the cyclotron resonance |
| NACC | Time-acceleration factor |
| R | Major radius [m] |
| phi | Toroidal angle [rad] |
| z | Vertical position [m] |
| omega_res | Resonance function |
| omega_c | Cyclotron frequency |
INPUT & OUTPUT
| mem | Resonance memory |
OUTPUT
| was_stored | TRUE if the new point was successfully stored in mem |
Definition at line 266 of file RFOF_resonance_memory.F90.
| subroutine RFOF_resonance_memory::storeNewPointResonanceMemory | ( | type(resonance_memory), intent(inout) | mem, |
| real(8), intent(in) | time_at_resonance, | ||
| real(8), intent(in) | time, | ||
| integer, intent(in) | nharm, | ||
| real(8), intent(in) | NACC, | ||
| real(8), intent(in) | R, | ||
| real(8), intent(in) | phi, | ||
| real(8), intent(in) | z, | ||
| real(8), intent(in) | omega_res, | ||
| real(8), intent(in) | omega_c, | ||
| logical, intent(out) | was_stored | ||
| ) |
Stores a new point in the memory mem. The new point is stored in the first element. All other points are moved one place in the memory list, except the last point which is removed from the list.
INPUT
| time_at_resonance | Estimated time of the resonance [s] |
| time | Present time [s] |
| nharm | Harmonic number of the cyclotron resonance |
| NACC | Time-acceleration factor |
| R | Major radius [m] |
| phi | Toroidal angle [rad] |
| z | Vertical position [m] |
| omega_res | Resonance function |
| omega_c | Cyclotron frequency |
INPUT & OUTPUT
| mem | Resonance memory |
OUTPUT
| was_stored | TRUE if the new point was successfully stored in mem |
Definition at line 345 of file RFOF_resonance_memory.F90.
| subroutine RFOF_resonance_memory::storeNewPointResonanceMemoryLocationJ | ( | type(resonance_memory), intent(inout) | mem, |
| integer, intent(in) | j, | ||
| real(8), intent(in) | time, | ||
| real(8), intent(in) | R, | ||
| real(8), intent(in) | phi, | ||
| real(8), intent(in) | z, | ||
| real(8), intent(in) | omega_res, | ||
| real(8), intent(in) | omega_c, | ||
| integer, intent(in) | nharm, | ||
| real(8), intent(in) | NACC | ||
| ) |
subroutine storeNewPointResonanceMemory
Store to the resonance memory mem, data for point along the orbit (time, R, phi, z) and the local resonance function omega_res and the harmonic resonance number nharm.
INPUT
| j | Index at which the point should be stored in mem |
| time | Time [s] |
| nharm | Harmonic number of the cyclotron resonance |
| NACC | Time-acceleration factor |
| R | Major radius [m] |
| phi | Toroidal angle [rad] |
| z | Vertical position [m] |
| omega_res | Resonance function |
| omega_c | Cyclotron frequency |
INPUT & OUTPUT
| mem | Resonance memory |
Definition at line 414 of file RFOF_resonance_memory.F90.
| subroutine RFOF_resonance_memory::estimate_resonance_location | ( | type(resonance_memory), intent(in) | mem, |
| real(8), intent(in) | time, | ||
| real(8), intent(in) | R, | ||
| real(8), intent(in) | phi, | ||
| real(8), intent(in) | z, | ||
| real(8), intent(in) | omega_res, | ||
| integer, intent(in) | nharm, | ||
| real(8), intent(in) | NACC, | ||
| real(8), intent(in) | time_previous_step, | ||
| real(8), intent(out) | time_at_resonance, | ||
| real(8), intent(out) | R_at_resonance, | ||
| real(8), intent(out) | phi_at_resonance, | ||
| real(8), intent(out) | z_at_resonance, | ||
| real(8), intent(out) | Dot_omega_res, | ||
| real(8), intent(out) | DotDot_omega_res, | ||
| integer, intent(in) | MPI_node_Id, | ||
| integer, intent(out) | errorFlag | ||
| ) |
Estimate the time and position of the nearby wave-particle resonances. Using the time history of the resonance function a quadratic extrapolation of the future position is performed.
INPUT
| mem | Resonance memory |
| time | Time [s] |
| time_previous_step | Time of previous step; i.e. resonance before this time should be ignored [s] |
| R | Major radius [m] |
| phi | Toroidal angle [rad] |
| z | Vertical position [m] |
| omega_res | Resonance function |
| nharm | Harmonic number of the cyclotron resonance |
| NACC | Time-acceleration factor |
OUTPUT
| time_at_resonance | Estimated time at the resonance [s] |
| R_at_resonance | Estimated major radius at the resonance [s] |
| phi_at_resonance | Estimated toroidal angle at the resonance [s] |
| z_at_resonance | Estimated vertical position at the resonance [s] |
| Dot_omega_res | Estimated time derivative of resonance function at the resonance [s] |
| DotDot_omega_res | Estimated second time derivative of resonance function at the resonance [s] |
| MPI_node_Id | Number to identify the MPI node |
| errorFlag | Error flag in case the resonance position was not found |
Definition at line 479 of file RFOF_resonance_memory.F90.
References polycoef_3points(), and wrap_save2file_resonace_predictions().
Here is the call graph for this function:| subroutine RFOF_resonance_memory::calc_non_accelerated_orbit_time_vec | ( | real(8), dimension(:), intent(in) | timeACC, |
| real(8), dimension(:), intent(in) | NACC, | ||
| real(8), dimension(:), intent(inout) | timeORBIT | ||
| ) |
Estimate the time and position of the nearby wave-particle resonances. Using the time history of the resonance function a quadratic extrapolation of the future position is performed.
Input
| timeACC | Accelerated time; differentials of this time is enhanced by a factor NACC |
| NACC | Time accelration factor |
Output
| timeORBIT | Time as experiencd by a real orbit as it moves in the devise |
Definition at line 685 of file RFOF_resonance_memory.F90.
| type(resonance_memory), dimension(:,:), allocatable, save RFOF_resonance_memory::resonanceMemoryAllWaves |
Definition at line 44 of file RFOF_resonance_memory.F90.
